ENDIzLED-106 , 5mm LED Strip lights 120/m
Bright, flexible, and easy to install — this high-density 2835 LED strip delivers clean daylight (6000–6500K) illumination ideal for task lighting, under-cabinet accents, display cases, signage, and any project that needs reliable, energy-efficient light.
Key benefits
- High brightness: 2835 LED chips provide strong, even light across the strip.
- Dense layout: 1200 LEDs on a 5m roll for smooth, continuous illumination with minimal hot spots.
- Energy efficient: 18 W per meter with excellent lumen output (≈100 lm/W).
- Flexible & cuttable: Bend to fit curves and trim at marked cut points (every 3 LEDs) for custom lengths.
- Strong adhesive backing: Peel-and-stick installation for quick mounting on clean surfaces.
- Wide compatibility: Operates on 12–24 V systems for versatile use.
- Durable: 24-month warranty for peace of mind.
Spec highlights
- LED chip: SMD 2835
- Color temperature: 6000–6500K (cool white)
- Length & density: 5 m roll — 1200 LEDs (high density)
- Power: 12 W per meter
- Brightness: ~100 lumen per watt
- Strip width: 5 mm
- Cut increment: every 3 LEDs
- Input voltage: 12–24 V
- Warranty: 24 months
Installation tips
- Prepare the mounting surface by wiping it clean and dry for best adhesive performance.
- Peel back the adhesive liner and press the strip firmly into place.
- Cut only at the marked scissor icons (every 3 LEDs) to avoid damaging the circuit.
- Wiring: connect red to V+ (positive) and black to C (CW) as indicated — use compatible connectors or a properly rated driver/power supply.
- For runs longer than a few meters, consider injecting power at intervals or using a suitable DC power supply to avoid voltage drop.
Ideal uses
- Under-cabinet and task lighting
- Display cases, shelving and retail lighting
- Cove and accent lighting
- Backlighting for TVs, photos, and signage
- Workshop and utility illumination
What’s included
- 5 m LED strip (1200 LEDs), adhesive backing
- Standard bare wire leads for power connection
Need help choosing a power supply or cutting/connecting multiple strips? I’d be happy to recommend compatible drivers and accessories to match your project — tell me the total length and installation type and I’ll help you pick the right components.
