ELEISH-002 — DC‑DC Step‑Down Converter (24V → 12V) 400W
Product overview
- The ELEISH-002 is a compact, high-efficiency DC‑DC step‑down converter that converts 24V DC to a stable 12V DC output. Designed for automotive, marine, solar and industrial applications where reliable 12V power is needed from a higher-voltage source.
Key features
- High conversion efficiency (synchronous rectification — up to ~96%) for lower heat and longer runtime.
- Robust aluminum-alloy heatsink body for excellent thermal dissipation.
- Waterproof and dust-resistant packaging with high ingress protection (designed for harsh environments).
- Built-in smart protections: over-temperature, over-current, short-circuit and over-voltage protection to safeguard both the converter and connected devices.
- Compact form factor with mounting holes for secure installation.
Typical specifications (useful reference)
- Input: 24V DC nominal (must remain within device’s allowable fluctuation range)
- Output: 12V DC regulated
- Body size: 74 × 74 × 32 mm (approx.)
- Weight: ~300 g (approx.)
- Efficiency: up to 96% (typical for synchronous designs)
Note: Confirm exact electrical ratings (max output current / power) from seller datasheet before pairing with high‑power loads.
Wiring & installation
- Wire identification (typical):
- Red = Input + (24V)
- Black = Input – (ground)
- Yellow = Output + (12V)
- Black (second ground) = Output – (ground)
- Important: Observe polarity — reversing +/– can damage the unit or load.
- Mount on a flat surface using the provided screw holes; allow clearance for airflow around the fins.
- Ensure the converter’s max output current exceeds the total required draw of connected devices.
Applications
- Vehicle electronics (convert 24V truck/bus systems to 12V accessories)
- LED lighting, CCTV cameras, stereo equipment
- RV, marine, solar and battery-powered systems
- Industrial control and instrumentation
Safety & tips
- Always verify the converter’s rated current and power against your device’s consumption before use.
- Fuse the input side near the power source for additional protection.
- If using outdoors or in wet locations, confirm the device’s IP rating and seal cable entries as needed.
If you’d like, I can:
- Draft a short product listing blurb for an online store.
- Create a concise wiring diagram or a one‑page spec sheet.
Which would you prefer?
